Description
This industrial-grade manual scissor lift pallet truck is constructed with a reinforced steel structure and precision robotic welding for durability and long-term performance. It features a single or double cast pump with a durable valve cartridge and a lifting capacity of 2200 lb. The pallet jack includes polyurethane wheels with steel hubs, padded handles for comfort, and a hydraulic lift system capable of raising loads up to 31.5 inches while lowering to 3.35 inches. Designed for warehouses and industrial environments, it provides efficient lifting and handling of palletized loads.
Features
-
Reinforced robotic welding
-
3-position control handles
-
Powder-coated paint finish
-
Ergonomic A-handle
-
Single or double cast pump with durable valve cartridge
-
Overload bypass valve prevents lifting beyond rated capacity
-
Top-of-stroke bypass secures the hydraulic system
-
Control lever automatically returns to neutral when released from the lower position
Specifications
General Information
-
Model: I10
-
Rated Capacity: 2200 lb
-
Load Center: 23.6 in.
-
Service Weight: 286 lb
Size
-
Wheel Material: PU
-
Fork Spread (B): 27 in.
-
Fork Length (L): 46 in.
-
Fork Width: 6.38 in.
Height
-
Lowered Fork Height (H1): 3.3 in.
-
Raised Fork Height (H): 31.5 in.
-
Lift Height: 28.15 in.
Dimensions
-
Overall Length: 59 in.
-
Ground Clearance: 0.71 in.
Wheels
-
Load Wheel: Φ2.95 × 1.97 in.
-
Steering Wheel: Φ7.1 × 2 in.
-
Steering Angle: 185°
Warranty
-
3 Years Limited Warranty
