Description
The EK50LP LPG 4-wheel forklift is designed to handle demanding material handling tasks in warehouses, distribution centers, and industrial environments. Built with a durable heavy-duty chassis, this forklift provides reliable performance and stability while transporting heavy loads.
The operator compartment features a non-slip entrance step, wider access, and increased leg room for improved comfort during operation. An adjustable steering column helps reduce operator fatigue, while the multifunction instrument panel supports safe and efficient operation. The steer axle pivot allows tight turning capability, improving maneuverability in confined working areas.
Key Features
-
Heavy-duty 4-wheel LPG forklift design
-
Multifunction instrument panel for monitoring and safety
-
Non-slip operator entrance step with wider access
-
Adjustable steering column to reduce operator fatigue
-
Excellent operator visibility
-
Integral heavy-duty chassis for operator protection
-
Steer axle pivot up to 80° for tighter turning radius
-
Hydraulic control system for smooth operation
Specifications
General
-
Model: EK50LP
-
Drive Type: LPG
-
Type of Operation: Propane
-
Load Capacity: 10,000 lb
-
Load Center: 24 in.
-
Lift Height: 185 in.
-
Service Weight: 16,250 lb
Dimensions
-
Wheelbase: 61.8 in.
-
Overall Width: 55.9 in.
-
Overall Length with Forks: 157 in.
-
Overall Length without Forks: 109 in.
-
Minimum Ground Clearance (at Mast): 4.3 in.
-
Mast Overall Height: 91.9 in.
-
Free Lifting Height: 44.3 in.
-
Backrest Height (from Fork Surface): 47.6 in.
Forks
-
Fork Size: 48 × 5.9 × 1.97 in.
Performance
-
Maximum Travel Speed (Loaded/Unloaded): 10.5 / 11.2 mph
-
Traction Tires: Cushion Pattern
-
Pin Height: 11.2 in.
Brakes
-
Service Brake: Hydraulic Foot Pedal
-
Parking Brake: Mechanical Hand Lever
Engine
-
Engine Model: Kubota WG3800
-
Rated Power: 63.2 HP / rpm
Product Documents
-
Product Specifications
-
Product Service Manual
Warranty
-
Manufacturer Warranty Available
