The EcoFlow 5kVA 48V Power Kits Are The World’s First Fully Integrated, Plug-And-Play Power Solution Designed Especially For Recreational Vehicles
Take your off-grid travel to the next level with the EcoFlow 5kVA 48V Power System—a revolutionary power solution designed for RVs, vans, and motorhomes. With its plug-and-play simplicity, this compact system delivers high-capacity energy to power all your appliances, from air conditioners to electric ovens. Experience silent, efficient, and eco-friendly energy that keeps you powered for up to 7 days.
The EcoFlow Power Kits boasts a robust 5kVA output capable of running two 13,500 BTU RV air conditioners simultaneously. With 4,000W continuous output and 8,000W surge power, you can effortlessly power heavy-duty appliances like electric grills, heaters, and induction cookers. Whether you’re camping in remote locations or navigating urban areas, this system ensures you’ll never be without power.
EcoFlow Power Kits 5kVA 48V Power System Features
Enjoy Up to 45kWh of Power Capacity to Last Even the Longest Road Adventure
Enjoy an expandable 45kWh capacity by stacking up to 9 batteries, providing uninterrupted energy for up to 7 days—ideal for extended road trips, off-grid living, and powering your lifestyle anywhere you go.
Easily Recharge With Solar, Shore Power, Vehicle Alternator, or Traditional Generator
Stay powered with versatile options, including solar, shore power, vehicle alternator, or generator. Achieve an impressive 11kWh recharge in just one hour with hybrid charging, ensuring your energy demands are met quickly and efficiently.
Whisper-Quiet Operation So You Can Power Your RV in Peace
Operates at an incredibly low 48 dB, delivering peaceful functionality for quiet nights at the campground or while traveling. Experience comfort and convenience without the intrusive noise typically associated with power systems.
Compact Design for Tight Installations
Engineered to be 50% smaller and lighter than comparable systems, this space-saving solution is perfect for tight installations, maximizing available room without sacrificing performance or functionality for your adventures.
Advanced Safety Features for Peace of Mind
Equipped with X-Guard BMS technology, this system offers comprehensive protection against overcharging, short circuits, and extreme temperatures. UL1973, UL458, and UL67 certifications guarantee reliable safety for peace of mind in any environment.
Smart Control and Monitoring With the PowerInsight App
The PowerInsight App lets you manage and monitor energy usage remotely from your smartphone, control up to 16 DC circuits, and automate charging for a seamless and worry-free power management experience.
EcoFlow Power Kits 5kVA 48V Power System Warranty
EcoFlow provides a 5-year warranty policy, ensuring the absence of defects in materials, workmanship, and performance during the warranty period.
What’s Included
- 1 x EcoFlow Power Kits 5kVA 48V Power System
- 1 x Bracket
- 1 x Adhesive
- 1 x M4*16 (2pcs for installation, 2 pcs for spare)
- 1 x RJ45 CAN Bus Cable (6m / Feet
- 1 x User Manual
EcoFlow Power Kits 5kVA 48V Power System Specifications
General Specifications |
|||
| Net Weight | 15.7kg | 34.6lbs | ||
| Dimension (mm) | 300 x 480 x 151 | ||
| Dimension (in) | 11.8 x 18.9 x 5.9 | ||
| Communication | Wi-Fi(2.4G, 5G), Bluetooth | ||
| GPS | Supported | ||
| IP Rating | IP 20 | ||
| Wi-Fi | 2.4G, 5G | ||
Output Specifications |
|||
| AC Output (Discharge Only) | 120V~4000W, 5000VA, 60Hz(Surge 10KVA) | ||
| AC Output (Bypass Mode) | 100-120V~50A Max, 50/60Hz | ||
| X-Fusion (Power Assist) | 33.3A Max, 5000VA Max | ||
| DC Output (12V/24V) | 13.6V⎓100A Max, 1360W Max; 26.4V⎓60A Max, 1584W Max | ||
| 48V DC Output / Smart Generator (48V) | 51.2V⎓55A Max | ||
| USB-A Output | 5V⎓2.4A Max | ||
| EF BUS Output (x2) | 12V⎓Total 1.2A Max | ||
| Total Output | 8752W Max | ||
Input Specifications |
|||
| AC Input (Bypass Mode) | 100-120V~50A Max | ||
| Alternator Input/PV Input 1 | 13–60V⎓100A Max, 4000W Max | ||
| Alternator Input/PV Input 2/3 | 13–60V⎓30A Max, 1600W Max | ||
| Battery 3 / Smart Generator | 40-57.6V⎓100A Max | ||
| 48V DC Output / Smart Generator (48V) | 40-57.6V⎓70A Max | ||
|
Battery Port
|
|||
| Charge | 40-57.6V⎓100A Max per port, total 270A Max | ||
| Discharge | 40-57.6V⎓100A Max per port, total 181A Max | ||
Operating Environment |
|||
| Operating Temperature | -25°C to 60°C (-13°F to 140°F), derating>40°C (104°F) | ||
| Operating Humidity | 0%-95% RH (non-condensing) | ||
| Altitude | <2,000 m (6,562ft) | ||
| Discharge Temperature | -25°C to 60°C (-13°F to 140°F), derating>40°C (104°F) | ||
| Storage Temperature | -25°C to 70°C (-13F to 158°F) | ||
| Warranty | 5 Years | ||
Accessories |
|||
| 30A AC/DC Smart Distribution Panel | ✓ | ||
| Power Link | ✓ | ||
| Power Dock | ✓ | ||
| 30/50A AC/DC Smart Distribution Panel | ✓ | ||
| 5kWh LFP Battery | ✓ | ||
| 2kWh LFP Battery | ✓ | ||
| PowerInsight Cabin (7-in) | ✓ | ||
| PowerInsight (10-in) | ✓ | ||
