Description
Give your back a break with the 90SR Tandem Axle Single Ram Dump Trailer, a light-duty trailer equipped with a straight ram hydraulic lifting system that makes dump outs easier than ever before. With the strength and durability needed for hauling and dumping mulch, dirt, and gravel, this reliable trailer is built to get the job done for those at home or on a farm.
And if you need to haul small equipment, say no more. An optional slide-in ramp package allows you to easily transport a piece of smaller equipment to wherever needed.
Standard Feature
Axles
2 – 5,200# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes
Forward Self-Adjusting Electric Brakes
Suspension
Multi-Leaf Slipper Spring w/ Equalizer
Tongue
6″ Channel
Coupler
Adjustable Forged
Safety Chains
1/4” Grd. 70 w/Safety Latch Hook (2 each)
Jack
8,000# Top Wind
Frame
6×2 Rectangular Tubing ILO 6″ Channel
Cross-Members
3″ Channel on 16″ Centers
Floor
12 Gauge Smooth Steel
Fenders
9” x 72” 14 Ga. Diamond Plate Double Square Broke
Ramps
Not Included – 6.5’ Slide In Ramp Package
Stake Pockets
Stake Pockets Along Both Sides (Quantity Varies by Length)
Trailer Plug
7-Way RV
Lights
Recessed, Grommet-Mounted L.E.D. Lighting
Wiring
Sealed, Modular Cold-Weather Wiring Harness
Tires
ST225/75 R-15 Load Range D Radial Tires
Bolt Pattern
6-Lug
Wheels
Black Mod Steel
Spare Mount
Side Spare Tire Mount
Spare Tire
Not Included – Spare Tire (ST225/75R-15 LR-D)
Paint Type
Professional Finish w/ Primer
Standard Paint Color
Black
Tie-Downs
(4) 1/2″ D-Rings Inside Bed to Secure Equipment
Cargo Control
Along Sides and Rear
Break-Away Kit
Complete System with Breakaway Cable
Battery
12V Deep Cycle
Charger
5A 110V On Board Battery Charger
Gate
Double Rear Doors
J-Hooks
Along Sides and Rear for Cargo Control
Power
Power Up/Power Down & Gravity Down Hydraulic Pump
Ram
Self-Contained Single Cylinder Lift
Sides
20″ Tall Sides (12-Gauge)
Storage
Lockable Pump and Battery Box Mounted in Front of Bed
Tarp
Not Included – Crank Style Roll Tarp
Top Rail
2″ x 2″ Square Tubing
Specifications
| Specification | 90SR-12 | 90SR-10 |
|---|---|---|
| Model | 90SR-12 | 90SR-10 |
| Pull Type | Bumperpull | Bumperpull |
| GVWR | 9990 lbs | 9990 lbs |
| GAWR (Ea. Axle) | 5200 lbs | 5200 lbs |
| Empty Weight | 2930 lbs | 2750 lbs |
| Cargo Capacity | 7060 lbs | 7240 lbs |
| Bed Length | 12′ | 10′ |
| Bed Width | 72″ | 72″ |
| A | 120 | 120 |
| B | 70 | 70 |
| C | 50 | 50 |
| Tongue Length | 45 | 45 |
