Description

When it’s time to work, it’s time for the 30SV Single Axle Vanguard Trailer. Built strong to haul your landscaping equipment from job to job without hassle, the 30SV features a pipe-top rail and higher sides to protect cargo and keep tools secure during transport.

If you’re ready to expand your landscaping operations, the optional rear ramp gate makes it easy to transport golf carts, ATVs, side-by-sides, and other small vehicles. Durable, reliable, and easy to use, the 30SV is designed to handle everyday hauling tasks with confidence.

Standard Features

Axles:
3,500# Premium Cambered Axle with Quick-Lubricating Hubs

Brakes:
Brake Flanges for Easy Brake Addition

Suspension:
Multi-Leaf Slipper Spring

Coupler:
Demco EZ Latch 2″ Forged Coupler

Safety Chains:
1/4″ Grade 30 with Safety Latch Hook (2)

Jack:
2,000# Top Wind, Set-Back Jack

Frame:
3″ x 2″ x 3/16″ Angle

Cross-Members:
3″ x 2″ x 3/16″ Angle

Floor:
Treated Pine or Douglas Fir

Fenders:
9″ x 32″ Rolled Formed with Back

Trailer Plug:
4-Way Flat with Loom

Lights:
L.E.D. D.O.T. Stop, Tail, Turn & Clearance

Wiring:
Grommet-Mounted Lifetime L.E.D. Lighting

Tires:
ST205/75 R-15 Load Range C

Bolt Pattern:
5 Bolt

Spare Mount:
Side Spare Tire Mount

Paint Type:
Professional Finish with Primer

Standard Paint Colors:
Black, Red, Grey, White, Desert Tan, Jet Blue, Slime Green, Implement Green, Equipment Orange, Medium Yellow

Tie-Downs:
(4) Tie Down Loops Inside Bed

Sides:
28-1/2″ Tall Sides with 24″ V-Crimped Steel Panels (16 Gauge)

Top Rail:
2″ x 2″ Square Tubing

Available Options

• Electric Brakes with Complete Break-Away Kit

• 2,000# Fold-Up Jack

• Blackwood Pro Rubber Infused Lumber Floor (per linear foot)

• 4′ Tall Rear Ramp Gate with Coil Spring Assist

• 5′ Tall Rear Ramp Gate with Coil Spring Assist

• Additional Stake Pockets

• Spare Tire (ST205/75R-15 LR-C)

• Additional Tie Loops

• Bolt-On Landscape Box (24″ x 24″ x 64-1/2″)

Specifications

Model 30SV-08

Pull Type: Bumperpull
GVWR: 2,995 lbs
GAWR (Each Axle): 3,500 lbs
Empty Weight: 870 lbs
Cargo Capacity: 2,125 lbs
Bed Length: 8′
Bed Width: 60″
A: 97-1/2″
B: 61″
C: 36-1/2″
Tongue Length: 36-1/8″

Model 30SV-10

Pull Type: Bumperpull
GVWR: 2,995 lbs
GAWR (Each Axle): 3,500 lbs
Empty Weight: 970 lbs
Cargo Capacity: 2,025 lbs
Bed Length: 10′
Bed Width: 60″
A: 121-1/2″
B: 73″
C: 48-1/2″
Tongue Length: 36-1/8″

Model 30SV-12

Pull Type: Bumperpull
GVWR: 2,995 lbs
GAWR (Each Axle): 3,500 lbs
Empty Weight: 1,070 lbs
Cargo Capacity: 1,925 lbs
Bed Length: 12′
Bed Width: 60″
A: 145-1/2″
B: 85″
C: 60-1/2″
Tongue Length: 36-1/8″
