Description
Gooseneck configured for superior stability and weight capacity, the 14RD Roll-Off Gooseneck Dump Trailer features a 15,900 lb GVWR to meet the demands of construction crews, junk removal companies, and dumpster rental businesses.
Built to service multiple job sites with a single trailer, the 14RD is equipped with professional-grade components designed to withstand heavy daily use. From its strong I-beam frame and scissor hoist lifting system to its industry-leading heavy-duty winch, this roll-off dump trailer is engineered to perform when the toughest jobs demand reliable equipment.
Standard Features
Axles:
2 – 7,000# Premium Cambered Axles with Quick-Lubricating Hubs
Brakes:
Forward Self-Adjusting Electric Brakes on Both Axles
Suspension:
Multi-Leaf Slipper Spring with Equalizer
Coupler:
Round Adjustable Pin 2-5/16″ Gooseneck Coupler
Safety Chains:
3/8″ Grade 70 with Safety Latch Hook (2)
Jack:
12,000# Drop-Leg Jack (Side Wind)
Frame:
8″ I-Beam (10#)
Cross-Members:
3″ Channel on 16″ Centers
Floor:
10 Gauge Smooth Steel
Fenders:
9″ x 72″ 14 Gauge Diamond Plate Double Broke
Trailer Plug:
7-Way RV
Lights:
Recessed, Grommet-Mounted L.E.D. Lighting
Wiring:
Sealed, Modular Cold-Weather Wiring Harness
Tires:
ST235/80 R-16 Load Range E Radial Tires
Bolt Pattern:
8-Lug
Spare Mount:
Side Spare Tire Mount
Paint Type:
Professional Finish with Primer
Standard Paint Color:
Black
Tie-Downs:
(4) 1/2″ D-Rings Inside Bed
Break-Away Kit:
Complete Breakaway System with Zip Breakaway Cable
Battery:
12V Deep Cycle Group 24 for Hoist
12V Group 24 AGM for Winch
Charger:
(2) 5A 110V On-Board Battery Chargers
Gate:
Barn Doors
Power:
Power Up / Power Down & Gravity Down Hydraulic Pump
Ram:
Self-Contained Scissor Hoist
Sides:
48″ Tall (12 Gauge) with Formed Channel Supports
Top Rail:
4″ x 3″ Rectangular Tubing
Storage:
Lockable Pump and Battery Box Mounted in Front of Bed
Tarp:
Fully-Formed Tarp Shroud with Crank Tarp & Rear Tarp Rod Holders
Rollers:
Greaseable Rollers
Steps & Handles:
Convenient Side-Step to Access Top Rail
Winch:
Specially Designed High Duty Cycle 15K Winch
Available Options
-
Tire Upgrade (ST235/80 R-16 LR-G)
-
Spare Tire & Wheel (ST235/80 R-16 LR-E)
-
Spare Tire Upgrade (ST235/80 R-16 LR-G)
-
Wireless Remote for Hoist
-
Wireless Remote for Winch
Specifications
Model 14RD-14
Pull Type: Gooseneck
GVWR: 15,900 lbs
GAWR (Each Axle): 7,000 lbs
Empty Weight: 3,760 lbs
Cargo Capacity: 9,860 lbs
Bed Length: 14′
Bed Width: 83″
