Description
For those in the construction, junk removal, and dumpster rental business that need a bumper pull roll-off trailer with more carrying capacity, the 16RB Roll-Off Bumper Pull Dump is the perfect solution. With heavier-weight axles that provide additional load capacity, this trailer is fully featured and designed from the ground up with professional-grade parts to meet the challenging demands of day-to-day use.
The 16RB combines a durable and strong I-beam frame design, a scissor-hoist lifting system, and an industry-leading heavy-duty winch to provide an efficient solution that gets more work done—all with a single bumper pull roll-off trailer.
Standard Features
- Axles: 2 – 8,000 lb Premium, Cambered Axles with Oil Bath and Valcrum Caps
- Brakes: Forward Self-Adjusting Electric Brakes on Both Axles
- Suspension: Multi-Leaf Slipper Spring with Equalizer
- Coupler: 2-5/16″ Ball, Adjustable Demco EZ Latch Coupler
- Safety Chains: 3/8″ Grade 70 with Safety Latch Hook (2 ea)
- Jack: 12,000 lb Drop-Leg Jack (Side Wind)
- Frame: 8″ Seamless I-Beam (10 lb)
- Cross-Members: 3″ Channel on 16″ Centers
- Floor: 10 Gauge Smooth Steel
- Fenders: 9″ x 72″ 14 Ga. Diamond Plate Double Broke
- Trailer Plug: 7-Way RV
- Lights: Recessed, Grommet-Mounted LED Lighting
- Wiring: Sealed, Modular Cold-Weather Wiring Harness
- Tires: ST215/75 R-17.5 Load Range E Radial Tires
- Bolt Pattern: 8-Lug
- Spare Mount: Side Spare Tire Mount
- Paint Type: Professional Finish with Primer
- Standard Paint Color: Black
- Tie-Downs: (4) 1/2″ D-Rings Inside Bed to Secure Equipment
- Break-Away Kit: Complete Breakaway System with Zip Breakaway Cable
- Battery: 12V Deep Cycle Gr 24 for Hoist, 12V GR24 AGM for Winch
- Charger: (2) 5A 110V On-Board Battery Charger for Hydraulic System and Winch
- Gate: Barn Doors
- Power: Power Up/Power Down & Gravity Down Hydraulic Pump
- Remote: Wireless Remote for Hoist and Winch
- Ram: Self-Contained Scissor
- Sides: 48″ Tall (12 Ga) with Formed Channel Supports
- Storage: Lockable Pump and Battery Box Mounted in Front of Bed
- Tarp: Fully-Formed Tarp Shroud with Crank Tarp & Rear Tarp Rod Holders
- Top Rail: 4″ x 3″ Rectangular Tubing
- Battery Box: Tilt Bed Mounted Battery Box for Independently Wired Winch Power System
- Rollers: Greaseable Rollers
- Steps & Handles: Convenient Side-Step to Access Top Rail
- Winch: Specially Designed High Duty Cycle 15K Winch
Available Options
- Adjustable Pintle in Channel in Lieu of Coupler
- 12,000 lb Electric/Hydraulic Jack by Stillwell™
- Spare Tire (ST215/75 R-17.5 Load Range H)
Specifications
| Specification | Details |
|---|---|
| Model | 16RB-14 |
| Pull Type | Bumper Pull |
| GVWR | 17,500 lbs |
| GAWR (Each Axle) | 7,000 lbs |
| Empty Weight | 3,310 lbs |
| Cargo Capacity | 11,910 lbs |
| Bed Length | 14 ft |
| Bed Width | 83 in |
