Description
Part of the all-new X-Series, the 14EH Equipment Trailer from Big Tex Trailers is engineered for professionals who demand durability and innovation.
The 14EH features APEX Fortified Lumber for superior deck durability and a Mega-Sized Toolbox for added storage capacity. It’s enhanced with a Full-Length Rub Rail, D-Rings, and Stake Pockets, providing multiple secure tie-down options for a variety of cargo.
The 14EH revolutionizes loading and unloading with its optional Self-Stabilizing Mega Ramps, offering unparalleled flexibility for all your hauling needs.
Standard Features
Axles
2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes
Forward Self-Adjusting Electric Brakes on All Hubs
Suspension
Multi-Leaf Slipper Spring w/ Equalizer
Coupler
Adjustable 2-5/16” Demco EZ Latch
Safety Chains
3/8″ Grade 70 w/ Safety Latch Hook (2 ea)
Jack
12,000# Drop-Leg Jack (Side Wind)
Frame
8″ I-Beam
Cross-Members
3″ Channel on 16″ Centers
Front Stop Rail
3/16″ Fabricated Front Stop Rail
Floor
APEX Fortified Lumber
Fenders
9” x 72” 14 Ga. Diamond Plate Double Square Broke w/ Back (Removable)
Ramps
5′ Tall, 16″ Stand Up Ramps (Spring Assisted)
Dovetail
40” Cleated Dovetail
Stake Pockets
Stake Pockets Along Both Sides (Quantity Varies by Length)
Trailer Plug
7-Way RV
Lights
L.E.D. D.O.T. Stop, Tail, Turn & Clearance
Wiring
Sealed, Modular Cold-Weather Wiring Harness
Tires
ST235/80 R-16 Load Range E Radial Tires
Bolt Pattern
8-Lug
Spare Mount
Front Spare Tire Mount
Spare Tire
Not Included
Rubrail
Rub Rail Along Both Sides
Tie-Downs
(6) 5/8″ D-Rings
Break-Away Kit
Complete Breakaway System w/ Zip Breakaway Cable
Storage
Lockable Toolbox Between Risers on Gooseneck Model
Mega-Sized Integrated Tongue Box with Lockable Lid (Bumper Pull Only)
Steps & Handles
Convenient Side-Step to Access Deck
Available Options
-
Adjustable Pintle in Channel in Lieu of Coupler
-
Adjustable 2-5/16″ Demco EZ Latch Gooseneck Coupler
-
36″ Wide Mega Ramps (D3 Models Only)
-
Super-Wide Ramps (60″ Tall x 30″ Wide) w/ Blackwood Pro-Filled
-
Tire Upgrade (ST235/80 R-16 LR-G)
-
Spare Tire & Wheel (ST235/80 R-16 LR-E)
Paint Colors Available
-
Black
-
Red
-
Grey
-
White
-
Desert Tan
-
Jet Blue
-
Slime Green
-
Implement Green
-
Equipment Orange
-
Medium Yellow
Specifications
| Model | Pull Type | GVWR | GAWR (Ea. Axle) | Empty Weight | Cargo Capacity | Bed Length | Bed Width |
|---|---|---|---|---|---|---|---|
| 14EH-16D3A | Bumperpull | 15400 lbs | 7000 lbs | 2860 lbs | 12540 lbs | 16′ | 83″ |
| 14EH-18D3A | Bumperpull | 15400 lbs | 7000 lbs | 3020 lbs | 12380 lbs | 20′ | 83″ |
| 14EH-20D3A | Bumperpull | 15400 lbs | 7000 lbs | 3150 lbs | 12250 lbs | 20′ | 83″ |
| 14EH-22D3A | Bumperpull | 15400 lbs | 7000 lbs | 3330 lbs | 12070 lbs | 22′ | 83″ |
| 14EHG-20D3A | Gooseneck | 15900 lbs | 7000 lbs | 3740 lbs | 12160 lbs | 22′ | 83″ |
| 14EHG-22D3A | Gooseneck | 15900 lbs | 7000 lbs | 3940 lbs | 11960 lbs | 22′ | 83″ |
| 14EHG-24D3A | Gooseneck | 15900 lbs | 7000 lbs | 4140 lbs | 11760 lbs | 22′ | 83″ |
