Description

Built to get the job done and not to show off, the 14LD Low Profile Dump is a no-frills trailer—meaning you don’t have to pay for features and optional equipment that you may not need for the work you do.

Engineered to perform in the toughest environments, the 14LD is a durable trailer with the strength and versatility to transport and dump a huge variety of loads. Its low profile design makes it easy to load and unload materials or equipment.

Built like you, this hardworking dump trailer gets the job done without breaking the bank.

Standard Features

Axles
2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs

Brakes
Forward Self-Adjusting Electric Brakes on Both Axles

Suspension
Multi-Leaf Slipper Spring w/ Equalizer

Tongue
8″ Seamless I-Beam Integrated w/ Frame (10#)

Coupler
2-5/16″ Ball, Adjustable Demco EZ Latch Coupler

Safety Chains
3/8″ Grade 70 w/ Safety Latch Hook (2 ea)

Jack
8,000# Top Wind Drop Leg

Frame
8″ Seamless I-Beam (10#)

Cross-Members
3″ Channel

Floor
1/8″ Smooth Steel

Fenders
9″ x 72″ 14 Ga. Diamond Plate Double Broke

Ramps
Rear Ramp Pockets (Ramps Not Included)

Stake Pockets
Stake Pockets Along Both Sides (Quantity Varies by Length)

Trailer Plug
7-Way RV

Lights
Recessed, Grommet-Mounted L.E.D. Lighting

Wiring
Sealed, Modular Cold-Weather Wiring Harness

Tires
ST235/80 R-16 Load Range E Radial Tires

Bolt Pattern
8-Lug

Wheels
Black Mod Steel

Spare Mount
Side Spare Tire Mount

Spare Tire
Not Included

Paint Type
Professional Finish w/ Primer

Standard Paint Color
Black

Tie-Downs
(4) 1/2″ D-Rings Inside Bed to Secure Equipment

Break-Away Kit
Complete Breakaway System w/ Zip Breakaway Cable

Battery
12V Deep Cycle

Charger
5A 110V On Board Battery Charger

Gate
Double Rear Doors

J-Hooks
Along Sides and Rear for Cargo Control

Power
Power Up / Power Down & Gravity Down Hydraulic Pump

Ram
Self-Contained Scissor

Sides
20″ Tall (12 Ga) with Formed Channel Supports

Steps
Convenient Side-Step to Access Top Rail

Storage
Lockable Pump and Battery Box mounted in Front of Bed

Tarp
Tarp Mounting Brackets on Front of Bed

Top Rail
2″ x 2″ Rectangular Tubing

Steps & Handles
Convenient Side-Step to Access Top Rail

Available Options

• Adjustable Pintle in Channel in Lieu of Coupler

• 6.5’ Slide In Ramp Package

• Spare Tire & Wheel (ST235/80 R-16 LR-E)

• 5 Watt Solar Charger

• Wireless Remote

• Rear Stabilizer Stands – Set of (2)

• Crank Style Roll Tarp

Specifications
